Learning goals
- I can use before–during–after records to explain temporary and remaining deformation.
- I can compare matched collision records using force, mass, motion and energy with stated limits.
Readings for this unit
Before this unit
Review the earlier motion graphs and Newton’s laws units. The visible language notes explain this unit’s quantities; then connect them to its concrete records and figure.
Use three teaching sessions of about 40–45 minutes: first observe the phenomenon, draft a model and study Parts 1–2; next explain Parts 3–4 with the figures and evidence; then work the application, examples, practice, model revision and exit check. Divide any difficult part into smaller steps and revisit after feedback. Investigations, review and quizzes have separate sessions. Study the four visual parts across the scheduled sessions, then use the illustrated worked case and independent transfer questions. Extend or revisit a session when the learner cannot explain the figure; completion time is a proposed allocation, not a mastery guarantee.
Start with something to explain
What would explain the observations in collisions, deformation & changes in motion?
Illustrative evidence case. Illustrative matched-cart tests show bumper thickness 15 mm before, 8 mm during and 15 mm afterward; peak force is 12 N rather than 24 N for a rigid stop.
Notice and wonder
Does recovered thickness establish that no energy transferred? Write two observations from the supplied record without guessing their cause. Include a quantity and its unit when given. An observation is what was recorded; an inference is what you think explains it.
Write one question about why the pattern occurs and one question about a comparison that could distinguish competing explanations. A testable question identifies what could be observed or measured.
Your first model
Before reading the model answer, sketch the named objects or particles and label what you think changes. Explain the temporary deformation and compare peak values without declaring all collisions safe. Keep this first version so you can compare it with your later explanation.
Build the language from the idea
- collision
- Short interaction in which objects exert forces on each other.
- deformation
- Change in an object’s shape.
- elastic deformation
- Shape change that substantially reverses after the force is removed.
- permanent deformation
- Shape change remaining after the interaction.
- peak force
- Largest force recorded during a specified interval.
- model
- A representation that explains selected features and makes predictions; it leaves other details out.
- evidence
- Relevant observations or records used to support or challenge a claim.
- system boundary
- The chosen limit separating the objects being studied from their surroundings.
- assumption
- A condition taken as true for a model or calculation and needing to be checked against the case.
A toy cart can hit soft packing material and stop without a permanent dent, while an otherwise similar collision against a hard stop can damage it. A collision is an interaction over a short interval when objects exert forces on each other.
Deformation means a change in shape. Elastic deformation is substantially reversed when the force is removed; permanent deformation remains.
Even a material that looks rigid can change shape slightly during contact. Study soft toy objects or supplied records, never a real phone, glass object, helmet or a person.
Temporary changes that escape normal-speed viewing can still matter to the explanation.
An observation is what a person or instrument records. An inference is a proposed interpretation of those records. Keep the two separate: a graph can show a pattern while more than one mechanism might explain it. State the chosen system, or part of the world being studied, and its boundary before accounting for material or energy transfers.
Use each figure as a reasoning tool. Read its caption and labels, describe the pattern, then explain a cause. If the picture is schematic, use the stated numbers rather than measuring its printed size. Check whether its simplified conditions match the problem before applying a formula.
Build your understanding
Where this fits
This unit helps answer the chapter question: What evidence lets us describe and predict motion? Keep a notebook table with the question, evidence, explanation and one unresolved issue. Revise a previous model only when you can name the new evidence or idea that changes it.
Use three teaching sessions of about 40–45 minutes: first observe the phenomenon, draft a model and study Parts 1–2; next explain Parts 3–4 with the figures and evidence; then work the application, examples, practice, model revision and exit check. Divide any difficult part into smaller steps and revisit after feedback. Investigations, review and quizzes have separate sessions.
Part 1 · Compare before, during and after contact
Observations before contact establish motion and shape; observations during contact can reveal bending or compression; afterward they show rebound or permanent change. A system model includes both objects and their surroundings. A cartoon with three frames is a model, not proof of unseen changes.
Read the visual model
A timeline is important because different interactions exist at different stages. An elastic collision is an ideal case where the system’s kinetic energy is retained after separation. A damaged or thermally dissipative collision can have a different outcome.
Why should the contact-force arrows not be carried into the separated after-collision snapshot?
Visual reasoning — after your attempt
The contact interaction has ended once the carts separate. A remaining velocity is not evidence of a continuing contact push; other real interactions must be named separately.
Illustrative foam bumper images show 20 mm thickness before contact, 12 mm during contact and 19 mm afterward. The shape mostly recovers but not exactly. A slow record permits an observation that a single after-collision photograph would miss.
Pause and explain
Why is an afterward photograph insufficient to detect temporary deformation?
Check your reasoning after answering
An object can deform during contact and then recover. The after-image does not show the complete time sequence.
Part 2 · Connect equal forces with different motion changes
During contact, each object exerts an equal-size opposite-direction force on the other. Different masses can undergo different accelerations under these equal interaction forces. For each object, include other forces before calculating a net force.
Read the visual model
Force equality belongs to the interaction pair. Acceleration also depends on the receiver’s mass and full force account. Calculate a change in velocity separately from the object’s already existing velocity.
Over an interval of 0.1 s at these average forces, what are the velocity changes?
Visual reasoning — after your attempt
A changes by 0.5 m/s left and B by 1 m/s right. Their acceleration and velocity changes differ even though the paired interaction forces are equal.
If the contact force dominates, a 1 kg cart and a 2 kg cart under equal 4 N contact forces have acceleration magnitudes 4 and 2 m/s². Metres per second squared describes the rate of velocity change, not the distance travelled.
Pause and explain
Does greater acceleration of the lighter cart imply a larger collision force on it?
Check your reasoning after answering
No. Equal interaction forces can cause different acceleration because masses differ, and net-force calculations must account for other forces.
Part 3 · Track energy and deformation without a damage shortcut
Kinetic energy is energy associated with motion. In the same simplified situation, more mass at the same speed means more kinetic energy, and doubling speed gives four times the kinetic energy. During stopping, energy can transfer into temporary deformation, thermal changes, sound and surroundings.
Read the visual model
A system boundary determines which energy changes are included. Temporary deformation may later release stored energy; permanent change and warming can remain. Specify the stage of the collision before deciding what the bars represent.
How much kinetic energy is no longer in motion here, and why is calling it destroyed incorrect?
Visual reasoning — after your attempt
2 J is no longer kinetic in this account. It is represented by thermal and deformation changes inside the stated full system, so total energy remains 4 J.
A supplied cart model has 1 J at one speed and 4 J at twice that speed. The energy ratio is useful, but damage also depends on contact area, material, duration and breaking limits. Equal energy does not guarantee equal damage.
Pause and explain
Can speed alone predict every dent?
Check your reasoning after answering
No. It influences motion energy, but material response, geometry and how the object stops also affect damage.
Part 4 · Evaluate a cushioning mechanism
Cushioning can allow a moving object to stop through a longer distance and time, often reducing typical and peak stopping forces for comparable starting motion. A peak force is the largest recorded force; it differs from the average over contact. A cushion that bottoms out can lose that advantage.
Read the visual model
Start with the time width and force height. Average force can be found from the measured velocity change and stopping time in this model. The force–time area is an optional further connection; it does not have units of distance or energy.
Compare average forces using mass×velocity change/time. Why is “soft-looking always protects” too strong?
Visual reasoning — after your attempt
The averages are 0.2×2/0.02 = 20 N and 0.2×2/0.08 = 5 N. Longer stopping time can reduce force for the same motion change, but a material may bottom out, change the stopping conditions or fail another requirement.
Illustrative tests for matched carts at the same speed show peak readings of 18, 19, 20 N without padding and 9, 10, 11 N with padding. Check repeated trials, measuring method and pad thickness before generalizing to other objects.
Pause and explain
What do these peak records support?
Check your reasoning after answering
Lower measured peak force for this padded setup under the stated matched conditions. They do not certify every pad or establish identical average forces or injury protection.
Apply the whole unit · Temporary shape and a peak reading
Illustrative case for analysis, not measurements collected by the learner. Illustrative matched-cart tests show bumper thickness 15 mm before, 8 mm during and 15 mm afterward; peak force is 12 N rather than 24 N for a rigid stop.
Your task
Explain the temporary deformation and compare peak values without declaring all collisions safe. Use the supplied conditions, show intermediate reasoning and distinguish the supported conclusion from a broader claim.
What your response should show
- Use the specified quantities and units.
- Explain an intermediate step or comparison.
- Connect the pattern to the physical mechanism.
- State an assumption or limitation.
Response guidance — after your attempt
Compare thickness at three times: 15→8→15 mm shows compression and recovery in the record.
Classify the modeled shape change as elastic because its thickness recovers.
Compare peaks: 12/24=0.5, so the padded peak is half the rigid-stop peak under matched conditions.
Relate cushioning to stopping time/distance and account for redistributed energy, while limiting the claim to these records.
The bumper undergoes elastic deformation in this simplified record because it regains its thickness. The padded peak is half the rigid-stop peak under matched conditions. Deformation can allow a longer stopping interval, but the readings do not prove that every object is protected or give the entire force–time history. Energy is redistributed rather than erased.
Scientific references and adapted teaching resources
- OpenSciEd 8.1 Contact Forces — public unit overview
- OpenSciEd instructional model — storyline routines
- Creative Commons Attribution 4.0 — middle-school material license
- OpenSciEd 8.1 Lesson 2 — Exploring Horizontal Collisions (public handout)
Parent / teacher teaching notes
Ask the learner to describe the phenomenon before naming a formula. Discuss each checkpoint after an attempt. Use the supplied records when equipment is unavailable and label them illustrative rather than actual measurements. The final explanation should identify a mechanism and a limit, with different defensible wording accepted. Adaptation credit: OpenSciEd middle-school teaching routines and public task structures by OpenSciEd, CC BY 4.0. This independent version adds original explanatory text, data and figures, terminology support and a home-study schedule. It does not reproduce the complete teacher editions or their classroom validation.
The key idea
It may have changed temporarily during contact; use a before–during–after record. The bumper undergoes elastic deformation in this simplified record because it regains its thickness.
Worked examples
Example 1 · Build the first reasoning step
- Identify what the question asks and what the stated observation establishes.
- An object can deform during contact and then recover. The after-image does not show the complete time sequence.
Example 2 · Temporary shape and a peak reading
- Compare thickness at three times: 15→8→15 mm shows compression and recovery in the record.
- Classify the modeled shape change as elastic because its thickness recovers.
- Compare peaks: 12/24=0.5, so the padded peak is half the rigid-stop peak under matched conditions.
- Relate cushioning to stopping time/distance and account for redistributed energy, while limiting the claim to these records.
Explain why each stated condition matters.
Example 3 · Transfer to a different condition
- Identify the changed condition.
- No. Different materials and stopping conditions can distribute the energy differently. Conservation does not require the same peak force, deformation or damage.
Example 4 · Find and fix the mistake
- Distinguish what is observed from what is inferred.
- It may have changed temporarily during contact; use a before–during–after record.
Compare the claim with the stated observations and model assumptions.
Example 5 · Interpret the visual model
- Identify the represented objects, axes, labeled quantities and stated conditions before choosing a rule.
- A timeline is important because different interactions exist at different stages. An elastic collision is an ideal case where the system’s kinetic energy is retained after separation. A damaged or thermally dissipative collision can have a different outcome.
- The contact interaction has ended once the carts separate. A remaining velocity is not evidence of a continuing contact push; other real interactions must be named separately.
Keep the model’s stated limits explicit: These equal-mass carts illustrate an ideal one-dimensional elastic collision: the initially moving cart can stop while the initially stationary cart moves. Interaction-force arrows apply during contact, while velocity arrows describe motion before or after. The snapshots omit detailed deformation and other forces and do not claim that all real collisions exchange velocities or conserve mechanical kinetic energy.
Avoid these mistakes
- It may have changed temporarily during contact; use a before–during–after record.
- Do not treat a schematic drawing as a scale measurement or a universal guarantee.
- Keep the stated comparison conditions and measurement boundary explicit.
- A correct numerical result needs units and an explanation of its meaning.
Check your understanding
Why is an afterward photograph insufficient to detect temporary deformation?
Discuss the answer
An object can deform during contact and then recover. The after-image does not show the complete time sequence.
Does greater acceleration of the lighter cart imply a larger collision force on it?
Discuss the answer
No. Equal interaction forces can cause different acceleration because masses differ, and net-force calculations must account for other forces.
Can speed alone predict every dent?
Discuss the answer
No. It influences motion energy, but material response, geometry and how the object stops also affect damage.
What do these peak records support?
Discuss the answer
Lower measured peak force for this padded setup under the stated matched conditions. They do not certify every pad or establish identical average forces or injury protection.
Return to the phenomenon
Illustrative matched-cart tests show bumper thickness 15 mm before, 8 mm during and 15 mm afterward; peak force is 12 N rather than 24 N for a rigid stop. Explain the temporary deformation and compare peak values without declaring all collisions safe. Revise your first explanation using a named idea from the lesson. Mark the changed part and the evidence that supports it.
Compare explanations after your attempt
The bumper undergoes elastic deformation in this simplified record because it regains its thickness. The padded peak is half the rigid-stop peak under matched conditions. Deformation can allow a longer stopping interval, but the readings do not prove that every object is protected or give the entire force–time history. Energy is redistributed rather than erased.
What should we investigate next?
Which condition could be changed to test a remaining uncertainty in this explanation? State the predicted observation and what result would challenge your model.
Investigate, explain and revise
Use these tasks after the three teaching sessions as needed. Discuss an attempted explanation before opening response guidance; a matching sentence is less important than a supported mechanism.
Activity 1 · Explain the new evidence case
Use the visible scenario above, Parts 1–4 and your first notebook model. No outside reading or equipment is required.
Your task
Illustrative matched-cart tests show bumper thickness 15 mm before, 8 mm during and 15 mm afterward; peak force is 12 N rather than 24 N for a rigid stop. Explain the temporary deformation and compare peak values without declaring all collisions safe. Write 100–150 words or give a labeled drawing with an equivalent oral explanation.
Success criteria
- Use two relevant stated records or conditions.
- Explain the mechanism rather than only repeat a definition.
- Label observation and inference.
- Name a changed model feature or a remaining uncertainty.
Hint
Read the stated boundary and conditions before selecting a relationship. The unit’s worked examples show intermediate steps.
Response guidance — discuss after your attempt
The bumper undergoes elastic deformation in this simplified record because it regains its thickness. The padded peak is half the rigid-stop peak under matched conditions. Deformation can allow a longer stopping interval, but the readings do not prove that every object is protected or give the entire force–time history. Energy is redistributed rather than erased.
Activity 2 · Read and extend the figure
Study the new labeled figure and its caption, then compare it with the associated teaching part.
Your task
Does recovered thickness establish that no energy transferred? Explain what each important label represents. Add one missing feature that would be needed for a different question, and explain why the original figure leaves it out.
Success criteria
- Answer the figure question with its stated labels.
- Connect the visual representation to the scientific idea.
- Identify a specific limitation from the caption.
- Propose a useful change without misrepresenting supplied evidence.
Hint
The three snapshots show temporary elastic deformation in a simplified bumper record. A photograph taken only after contact would miss the compression. The model does not assign a force from thickness alone or certify real protective equipment, and it omits the full time-dependent motion.
Response guidance — discuss after your attempt
No. Energy can transfer through deformation, motion, sound and thermal pathways even if the original shape returns. The three snapshots show temporary elastic deformation in a simplified bumper record. A photograph taken only after contact would miss the compression. The model does not assign a force from thickness alone or certify real protective equipment, and it omits the full time-dependent motion.
Words to know
- collision
- Short interaction in which objects exert forces on each other.
- deformation
- Change in an object’s shape.
- elastic deformation
- Shape change that substantially reverses after the force is removed.
- permanent deformation
- Shape change remaining after the interaction.
- peak force
- Largest force recorded during a specified interval.
- model
- A representation that explains selected features and makes predictions; it leaves other details out.
- evidence
- Relevant observations or records used to support or challenge a claim.
- system boundary
- The chosen limit separating the objects being studied from their surroundings.
- assumption
- A condition taken as true for a model or calculation and needing to be checked against the case.
In the real world
Illustrative matched-cart tests show bumper thickness 15 mm before, 8 mm during and 15 mm afterward; peak force is 12 N rather than 24 N for a rigid stop.
Exit check
Does recovered thickness establish that no energy transferred? Explain the relevant mechanism and one model limitation.
Check your explanation after answering
No. Energy can transfer through deformation, motion, sound and thermal pathways even if the original shape returns. The three snapshots show temporary elastic deformation in a simplified bumper record. A photograph taken only after contact would miss the compression. The model does not assign a force from thickness alone or certify real protective equipment, and it omits the full time-dependent motion.
Explain your reasoning without notes. If a key idea is missing, revisit the lesson and try again.
